Sunday 4 December 2011

Build your own Wind Turbine


A wind turbine is a device that converts kinetic energy from the wind into mechanical energy.This turbine can be used for many purposes such as producing electricity,grinding grain or pumping water.

In this project we are talking about how we can use it to produce electricity.

Instruction guide PDF :
Build your own wind turbine



Concept :

Electricity is generated by the movement of a loop of wire, or disc of copper between the poles of a magnet and this movement would be produced by our wind turbine.

Things to know :

Nearly every electric generator has a starter and a rotor. The rotor, a magnet, is placed inside the start and rotates there.If you want first build electric generator using method given here and then connect it with our wind turbine.

Wind Turbine based on Instruction guide above :



More info about the video

Pedal Powered Washing Machine


Pedal Powered Washing Machine

A washing machine is a machine designed to wash laundry, such as clothing, towels and sheets.Generally these machines has been powered by electrical energy but pedal powered machine runs with our energy.

Pedal powered washing machines can be very useful for rural places in developing countries where electricity is out of reach. Moreover , in developed countries too ,it can be used to save electricity and getting some work out.

Concept :

It is based on very simple concept.This machines has pedals which are connected with steel ring inside the drum or box. When we cycle pedals to revolve the ring inside the drum with clothes and detergent ,it started to work like any electric machine as shown in Video below.

Related Video :

Maya Pedal :



Innovative India :

Thursday 24 November 2011

Remote controlled aircraft


This mechanical engineering project is about the construction of a flying model of an air craft controlled by a remote control. The materials for construction include light weight materials like wood, plastic and foam.

The tasks included in this working project are:
1. Building the body of the RC plane.
2. Building the RC plane controls.
3. Building the Electronic controls.
rc airplane controls
The four primary controls of an RC plane, collectively called control surfaces, are:

1. Throttle
2. Elevator
3. Ailerons
4. Rudder

The flight of the plane is directed by the movements of these control surfaces. The control surfaces are controlled by small servo motors which are in turn controlled using the remote control.

Even when the plane is made it is not easy to control it without crashing your model several times. So it is better to take a flight video each time you try to fly it, so that if the model is destroyed beyond repair, you may be able to present the video during your project evaluation.

Useful references:

http://www.rc-airplane-advisor.com/
http://www.rc-airplane-world.com/rc-airplane-controls.html

Ball Sorting Mindstorms Lego Project


Ball sorting project is interesting one because it helps you to understand various important concepts of Robotics such as finding distance of objects , recognizing them , pick and drop them and things like that.

Useful Links :

Sort the Ball
NXT Sensors

Hardware Requirement :

Lego Mindstorms NXT 2.0 which includes :

1) Ultrasonic sensor
2) Touch sensors: Lets the robot react to touch
3) Servo motors: Allows the robot to interact with the environment
NXT Brick: The programmable core that reads the sensors and controls the motors and things many more. You can buy it from any online store including amazon.com


Software Requirement :


NXT-G : is a graphical programming environment that comes bundled with the NXT. With careful construction of MyBlocks to encapsulate complexity, NXT-G can be used for real-world programming.

Complete Instruction and Details at Robin Newman's Page

Related Video :

Talking Robots with Lego Mindstorms



From the days of "Small Wonder" TV show , I always wanted to have one robot which can talk and response just like human.To build one as Robotic Project is really interesting. This project is going to be very interesting and challenging because our robot requires not only speak capability but should have artificial intelligence to learn from its surroundings.

Architecture for talking robots consists of four main modules:

1) Dialogue system
2) Speech client with speech recognition and synthesis capabilities
3) Module for infrared communication between the PC and the RCX and
4) the program that runs on the RCX itself.

Useful PDF:

Talking Robots With LEGO MindStorms

Related Video :

Tuesday 22 November 2011

Automatic parallel parking cars

What is Automatic Car Parking ?

Automatic parking is an autonomous car maneuvering from a traffic lane into a parking place to perform parallel parking, perpendicular or angle parking.


What's the importance of this topic?

Parking is one of the challenging thing for humans in Car Driving. Even though , lot of solutions available for smooth and safe driving such as car collision avoidance system, but very less focus is given to the the automatic parking system till recently. Although,many cars are now available with this feature such as Toyota Prius , still there is a long way to go.

For Whom :

Mechanical, Electrical, Electronics and Computer Science , almost all branches engineering students.

Level : Difficult


It is not an uncomplicated task to build up automatic parking expertise for a car. First of all, the car must be able to sense the surroundings, to find a free parking space and to detect obstacles in the car park.
Secondly, it should have the capability to plan the movement itself from the input of sensitivity system.
Lastly, it should be able to go after the premeditated motion sequences and to make sure that a goal position is reached, regardless of noise and errors.

Useful Links


How Self Parking Works ?
Camera based intelligent parking system

Related Video :



Source Code :

Java : Vehicle Parking

Related Projects :

Mechanical Projects
Robotics Projects

Audio amplifier

What is Audio amplifier?

How to make audio amplifiers?



Related PDF Files :

1) Berkeley final project Audio amplifier details (pdf)

2) Designing and Building a Subwoofer Amplifier

Submitted By - Er. Rahul Jaybhaye (B.E Elect.)

Mechanical Stair Climbing Robot


Stair Climbing Robots : Modern day robot needs to do extraordinary things in extraordinary circumstances. In a fire fighting time, there is time when it needs to climb stairs on its own , not only climb but find out when to climb and when to move forward.

To achieve that ,we need to design our robot in such a way that it can move forward as well as climb stairs easily. To achieve that , engineers use various techniques similar to innovative wheel design as shown in video.

Related PDF :
1) Stair Climber
2) Autonomous Stair Climbing


Monday 21 November 2011

The Fuel Energizer

The Fuel Energizer is a frequency resonator that uses Neodymium Super Conductor Magnets, which break and then realign the hydrocarbon chains in the fuel passing through the fuel line of your vehicle. The magnetic field created by the Fuel Energizer ionizes the fuel being fed to the engine, which itself produces a more complete combustion, maximizes fuel economy, improves fuel efficiency and reduces polluting emissions.

By installing these Neodymium Super Conductor Magnets close to your carburetor/injection system, your vehicle will start to feel the result of the Resonance frequency of the Neodymium Super Conductor Magnets and by making the fuel flow smoother your engine will run more efficiently. The way to ensure that you will gain the best results from The Fuel Energizer is by following the easy "Golden Seven Steps Rule".

Comes in Tamper Proof Packing.Special Benefits of The Fuel Energizer:

Upto 28% Fuel saving on your mileage per litre
Increased acceleration
Reduction in AC drag
Upto 40% Reduction in Carbon Monoxide emissions
Reduction in exhaust smoke
Extends your engine life, cleans out carbon deposits
Upto 30% increase in life of your catalytic convertor exhaust system
A smoother running engine

How does The Fuel Energizer Work?

Most fuels for internal combustion engines are liquid, but liquid fuels do not combust until they are vaporized and mixed with air. Most emissions from motor vehicles consist of unburned hydrocarbon, carbon monoxide, and oxides of nitrogen. Unburned hydrocarbon and oxides of nitrogen react in the atmosphere and create smog. Smog is the prime cause of eye and throat irritation, noxious smells, plant damage and decreased visibility. Oxides of nitrogen are also toxic.

Generally, fuel for an internal combustion engine is composed of a set of molecules. Each molecule consists of a number of atoms made up from a nucleus and electrons which orbit around their nucleus. Magnetic movements already exist in these molecules and they therefore already have positive and negative electrical charges. However, because these molecules have not been realigned, the fuel is not actively interlocked with oxygen during combustion, the fuel molecules or hydrocarbon chains must be ionized and realigned. This ionization and realignment is achieved through the application of the magnetic field created by the Fuel Energizer.

Fuel mainly consists of hydrocarbons and when fuel flows through a magnetic field, such as the one created by the Fuel Energizer, the hydrocarbons change their orientation and molecules of hydrocarbon change their configuration. This has the effect of ensuring that the fuel actively interlocks with the oxygen, producing a more complete burn in the combustion chamber. The result is higher engine output, better fuel economy and a reduction in the hydrocarbons, carbon monoxide and oxides of nitrogen that are emitted through the exhaust. The ionization of the fuel also helps to dissolve the carbon build-up in carburetor jets, fuel injectors and combustion chambers, thereby keeping the engine in a cleaner condition.

The Fuel Energizer can be used in:

Comes in Tamper Proof Packing.
Cars
Scooters
Ambulances

Tricycle powered by pedals and electricity


Tricycle which is powered by electricity would be very helpful for people who use cycles in there daily life. It would not only increase speed of the cycle but also helps them in paddling.

Concept :

Concept of this project is same as many electric vehicles we discussed before in Automobile Projects. It is powered by motor which is connected with battery that is charged with regular electricity available at home.
If you want , you can use some solar plates in vehicle itself to charge its batteries.

Why Tricycles?

There are many advantages in using tricycle :

1) It is lighter than any vehicle around
2) It can be used to carry more than one person
3) There are pedals so dependence on electricity is not as much as motor bike.
4) Enough space to place large battery.


Related Video :

Sunday 20 November 2011

Solar Powered Air Conditoner


Air conditioners are both cause and solution of global warming, due to rise in temperature in recent years, it becomes necessary for each one of us to have air conditioner. It has become very important part of our life in recent years. The only problem is that it consumes great amount of electricity which results is more global warming.

One of the best solution of above problem is air conditioner which do not use electricity generated by pollution generating fuel, instead use something renewable and unconventional. One of the example for that is Solar Powered Air conditioner which takes its power from solar.Solar air conditioning refers to any air conditioning (cooling) system that uses solar power.

This project is part of solar project ideas and can be used by students of Mechanical or Electronics engineering. Even students of Physics would find it interesting.If this project is implemented with Passive Solar Design , it would be more effective.

Related PDF :

1) SAC
2) Solar Driven Absorption Air Conditioning Systems for the Caribbean
3) Liquid Dessicated Solar Air-Conditioner

Related Presentation(ppt):

1) Solar Desiccant Air Conditioning


How Solar Air Conditioning Works ?
